| Brand Name : | ZXTLCD |
| Model Number : | ZXTLCD-IFP750WIC |
| Certification : | CE/Rohs/FCC |
| Price : | negotiable |
| Payment Terms : | L/C,T/T,MoneyGram,Western Union |
| Supply Ability : | 2000 pcs per month |
| Delivery Time : | 3-5 working days |
1.comprehensive safety lock function, provide U disk lock, screen lock, application software lock, touch lock.
2. image mode, provide the setting in the signal source channel, what you see is what you get, no need to exit the menu setting.
3. a variety of sound mode selection, provide the choice of sound device function, can choose the horn, USB microphone, etc., and support the equalizer function.
4. Adaptive ambient light function, which supports adjusting the screen brightness according to the ambient light, and the system supports the anti-blue light eye protection mode to protect the user's eyes.
5. Multi-in-one power button, supporting two-in-one and three-in-one setting modes (realize energy saving, switch OPS computer, and all-in-one machine).
Simplify your classroom or meeting space with the ultimate all-in-one interactive flat panel. This device integrates the functionality of a tablet, computer, projector, whiteboard, curtain, and audio system into a single compact solution. Whether it’s teaching, brainstorming, or collaborating, this versatile design empowers seamless, interactive learning and enhances productivity.
Smooth Writing Experience
Unleash creativity with a writing experience that feels as natural as pen on paper. The infrared-sensitive touch technology offers 1.0mm precision, ensuring smooth and accurate annotations. Whether it’s brainstorming ideas or teaching a lesson, this precision inspires collaboration and keeps everyone engaged.
Intelligent Whiteboard
Reimagine classroom interactivity with a whiteboard that does it all. Switch effortlessly between tools like table, ruler, pen, and eraser. Need to share content? Simply generate a QR code for instant sharing. This intelligent whiteboard unlocks endless possibilities for interactive and collaborative learning.
| name | size | 75" |
| show | Display Area HV (mm) | 1654mm ×931mm |
| optimum resolution | 3840×2160 pixels | |
| Refresh the frequency | 60Hz | |
| luminance | 300-350cd/m2 | |
| contrast ratio | 1200:1 / 5000:1 (OC) | |
| Visual Angle | 1780(H/V) | |
| Show color | 8bit 16.7M/1.07B (10bit) | |
| backlight | DLED | |
| colour gamut ntsc | 72% | |
| life span | For 50,000 hours | |
| surface | Body material | Aluminum alloy face frame, oxidation sandblasting process |
| Front frame color | Black [standard], can be customized silver black or other colors | |
| Front frame glass | Physical tempered grade 7 explosion-proof glass / anti-glare explosion-proof grade 7 tempered glass | |
| Front box pen slot | The two magnetic grooves on the front | |
| Touch parameters | Identification principle | Infrared recognition |
| Touch embedding mode | Built-in integrated type | |
| The way of writing | Finger, touch pen or other 2mm non-transparent object (full screen writing) | |
| Number of touch points | At 20 o'clock | |
| Touch resolution | 32767*32767 | |
| Touch precision | ±1mm | |
| Single refers to the response speed | ＜8ms | |
| Touch number | The theoretical number is infinite | |
| drivers | System automatic identification, no drive | |
| support system | windowsXP /7/8/10/11,Android,MacOS,Linux | |
| working temperature | -10~+50 ℃ | |
| communication mode | USB 2.0/USB 3.0 | |
| Built-in system | scheme | Amlogic T982 |
| CPU | Quad-core ARM Cortex-A55 | |
| GPU | Mali-G52 MP2(2EE) | |
| basic frequency | 1.9GHz | |
| internal storage | 4G DDR | |
| memory | 32GB (EMMC) | |
| Wi-Fi | 2.4GHz/5GHz | |
| System version | Android 13.0 | |
| Front interface | Enter the port | USB 3.0×3 |
| HDMI×1 | ||
| TOUCH USB×1 | ||
| Type-C×1 | ||
| Prehole position | Auto photosensitive hole 1 | |
| Remote control receives the indicator light 1 | ||
| key | Eight buttons | Switch, volume +, volume-, eye protection, recording screen, home page, setting, touch switch (single button optional) |
| The machine interface | Enter the port | RJ45:×1 |
| TOUCH USB:×1 | ||
| USB3.0:×1 | ||
| USB2.0:×1 | ||
| RS232:×1 | ||
| HDMI IN:×1 | ||
| AV IN:×2 | ||
| Other ports | AV OUT :×1 | |
| Earphone:×1 | ||
| SPDIF OUT:×1 | ||
| Complete machine power consumption | The power of the machine | ≤340W |
| OPS power | ≤110W | |
| working voltage | 100~240V AC, 50/60Hz | |
| Standby power consumption | ≤0.5W | |
| Sound channel stereo | 2.0 | |
| Dual-channel power | 20W / 8 Euro 2 speakers | |
| Built In camera | Built-in 48 million camera, 8 array microphones | |
| work environment | service temperature | 0~40℃ |
| operation humidity | 10%~90% RH | |
| Storage temperature | -20~60℃ | |
| Store humidity | 10%~90% RH | |
| above sea level | 5000 Meters | |
| Size weight | Standard bare machine size length * width * height (mm) | 1707×108×1013 |
| Camera bare machine size: length * width * height (mm) | 1707×108×1026 | |
| Overall machine package dimensions length * width * height (mm) | 1880×210×1150 | |
| VESA stent hole position (mm) | 400(V)×600(H) | |
| Wall hanging thickness (mm) | 30mm | |
| net weight | 47KG | |
| rough weight | 60KG | |
| Single outlet wooden box size: length * width * height (mm) | 19502651310 (with base support) | |
| Weight (including wooden box) | 90KG | |
| Standard list | nameplate (neutral) | 1 (affixed on the back of the whole machine) |
| QR code (Neutral) | 1 (at bottom left of front box) | |
| Accessory box (neutral) | ×1 | |
| Power supply line is 1.8M | 1 (98 inches standard with 3 m) | |
| Certificate of qualification (neutral) | ×1 | |
| Warranty Card (Neutral) | ×1 | |
| Remote control (battery-free) | ×1 | |
| Touch pen (magnetic suction) | ×2 | |
| Wall-hanger (neutral) | ×1 | |
| Optional list | HDMI line | ×1 |
| TOUCH USB Line | ×1 | |
| Intelligent page turning pen | ×1 | |
| Wireless screen casting device | ×1 | |
| traversing carriage | ×1 | |
