| Brand Name : | ZXTLCD |
| Model Number : | ZXTLCD-IFP1100WIR |
| Certification : | CE/Rohs/FCC |
| Price : | negotiable |
| Payment Terms : | L/C,T/T,MoneyGram,Western Union |
| Supply Ability : | 2000 pcs per month |
| Delivery Time : | 3-5 working days |
Think about the last time you were in a meeting where technology became more of a hurdle than a help—cables everywhere, blurry projectors, or constant interruptions. Interactive panels change all that by making presentations smooth, intuitive, and visually stunning.
With crystal-clear 4K visuals, your data, graphics, and presentations shine, keeping your audience focused and impressed. These panels go beyond static slides—they allow you to bring multimedia elements to life, annotate on the spot, and involve remote participants as if they were in the same room.
Product functions:
It can monitor the temperature value of the whole machine in real time, and the temperature can be displayed on the Android home page, prompting different colors. Automatic close the whole machine when the temperature of the whole machine is too high.
Adaptive ambient light function, which supports adjusting the screen brightness according to the ambient light, and the system supports the anti-blue light eye protection mode to protect the user's eyes.
Centralized control, through the external equipment for the whole machine volume, channel, sound, signal source and other functional operation.
Wired and wireless network Settings, support online network upgrade, support the system running time display function, can be viewed at any time.
Collaboration becomes seamless, whether it’s brainstorming ideas with your team, leading a high-stakes client pitch, or running a training session. Interactive panels streamline the process, letting you focus on the conversation instead of troubleshooting tech issues. They’re not just tools—they’re a game-changer for any modern workspace, helping you deliver impactful communication with ease.
Intelligent channel identification, automatically jump after inserting the signal source, and prompt the inquiry dialog box.
| name | size | 110" |
| show | Display area | 2436.5mm(H)×1370.5mm(V) |
| optimum resolution | 3840×2160 pixels | |
| Refresh the frequency | 60Hz | |
| luminance | 350-450cd/m2 | |
| contrast ratio | 1200:1 | |
| Visual Angle | 1780(H/V) | |
| Show color | 8bit 16.7M/1.07B (10bit) | |
| backlight | DLED | |
| colour gamut ntsc | 72% | |
| life span | For 50,000 hours | |
| surface | Body material | Aluminum alloy face frame, oxidation sandblasting process |
| Front frame color | Black [Standard] | |
| Front frame glass | Physical tempered grade 7 explosion-proof glass | |
| Front frame button | 1-way two-color switch (three-in-one setting: energy saving, switch OPS computer, switch machine) | |
| Touch parameters | Identification principle | Infrared recognition |
| Touch embedding mode | Built-in integrated type | |
| The way of writing | Finger, touch pen or other 2mm non-transparent object (full screen writing) | |
| Number of touch points | At 20 o'clock | |
| Touch resolution | 32767*32767 | |
| Touch precision | ±1mm | |
| Single refers to the response speed | ＜8ms | |
| Touch number | The theoretical number is infinite | |
| drivers | System automatic identification, no drive | |
| support system | windowsXP /7/8/10/11,Android,MacOS,Linux | |
| working temperature | -10~+50 ℃ | |
| communication mode | USB 2.0/USB 3.0 | |
| Built-in system | scheme | Amlogic T982 |
| CPU | Quad-core ARM Cortex-A55 | |
| GPU | Mali-G52 MP2(2EE) | |
| basic frequency | 1.9GHz | |
| internal storage | 4G DDR | |
| memory | 32GB (EMMC) | |
| Wi-Fi | 2.4GHz/5GHz | |
| System version | Android 13.0 | |
| Front interface | Enter the port | USB×2 |
| HDMI×1 | ||
| TOUCH USB×1 | ||
| Prehole position | Auto photosensitive hole 1 | |
| Remote control receives the indicator light 1 | ||
| The machine interface | Enter the port | RJ45:×1 |
| TOUCH USB:×1 | ||
| USB3.0:×1 | ||
| USB2.0:×1 | ||
| RS232:×1 | ||
| HDMI IN:×2 | ||
| AV IN:×1 | ||
| Other ports | AV OUT:×1 | |
| Earphone:×1 | ||
| SPDIF OUT:×1 | ||
| Complete machine power consumption | The power of the machine | ≤880W |
| OPS power | ≤120W | |
| working voltage | 100~240V AC, 50/60Hz | |
| Standby power consumption | ≤0.5W | |
| Sound channel stereo | 2.0 | |
| Dual-channel power | 15W / 8 O. 2 speakers | |
| work environment | service temperature | 0~40℃ |
| operation humidity | 10%~90% RH | |
| Storage temperature | -20~60℃ | |
| Store humidity | 10%~90% RH | |
| above sea level | 5000 Meters | |
| Size weight | Standard bare machine size is long | 2503mm (length) * 109mm (width) * 1470mm (height) with OPS |
| Camera model naked machine ruler | 2503mm (length) * 109mm (width) * 1484mm (height) with OPS | |
| packing measurement | 2685mm (length) * 285mm (width) * 1710 (height) (world cover) | |
| VESA stent hole position (mm) | ||
| Wall hanging thickness (mm) | 36mm | |
| net weight | 130KG | |
| rough weight | 155KG | |
| Standard list | nameplate (neutral) | 1 (affixed on the back of the machine) |
| QR code (Neutral) | 1 (at bottom left of front box) | |
| Accessory box (neutral) | ×1 | |
| Power line 3 meters | ×1 | |
| Certificate (neutral) | ×1 | |
| Warranty Card (Neutral) | ×1 | |
| Remote control (no battery) | ×1 | |
| Touch the pen | ×2 | |
| Wall-hanger (neutral) | ×1 | |
| Optional list | HDMI line of 3 m | ×1 |
| TOUCH USB Line is 3 meters | ×1 | |
| Intelligent page turning pen | ×1 | |
| Wireless screen casting device | ×1 | |
| traversing carriage | ×1 |
