Shenzhen ZXT LCD Technology Co.,Ltd
1 Years
| Ask Lasest Price | |
| Brand Name : | ZXTLCD |
| Model Number : | ZXTLCD-IFP1100KIR |
| Certification : | CE/Rohs/FCC |
| Price : | negotiable |
| Payment Terms : | L/C,T/T,MoneyGram,Western Union |
| Supply Ability : | 2000 pcs per month |
| Delivery Time : | 3-5 working days |
centralized control, through the external equipment for the whole machine volume, channel, sound, signal source and other functional operation.
Provide up to more than 12 language choices, and support the system interface, setting interface, application software, etc., the whole system multi-language follow the system language switch.
System optimization software, provide system overview, application software management, system memory optimization; support the monitoring and alarm of system information, ops computer, touch screen, temperature and screen.
Simplified Interaction
Say goodbye to outdated, cumbersome presentation methods. This 75-inch interactive flat panel allows for seamless, interactive experiences, eliminating barriers to creativity and collaboration. It’s designed to simplify how you share ideas and information.
Support the centralized control of this machine, and operate the volume, channel, sound, signal source and other functions through the external equipment.
Time-Efficiency
Access powerful digital tools instantly, reducing preparation time and increasing productivity. Whether for educators or professionals, this device streamlines workflows, leaving more time for meaningful discussions and problem-solving.
With the front recording screen function button, the courseware, audio and environmental sound in the host can be recorded at the same time.
| name | size | 110" |
| show | Display area | 2436.5mm(H)×1370.5mm(V) |
| optimum resolution | 3840×2160 pixels | |
| Refresh the frequency | 60Hz | |
| luminance | 350-450cd/m2 | |
| contrast ratio | 1200:1 | |
| Visual Angle | 1780(H/V) | |
| Show color | 8bit 16.7M/1.07B (10bit) | |
| backlight | DLED | |
| colour gamut ntsc | 72% | |
| life span | For 50,000 hours | |
| surface | Body material | Aluminum alloy face frame, oxidation sandblasting process |
| Front frame color | Black [Standard] | |
| Front frame glass | Physical tempered grade 7 explosion-proof glass | |
| Front frame button | 1-way two-color switch (three-in-one setting: energy saving, switch OPS computer, switch machine) | |
| Touch parameters | Identification principle | Infrared recognition |
| Touch embedding mode | Built-in integrated type | |
| The way of writing | Finger, touch pen or other 2mm non-transparent object (full screen writing) | |
| Number of touch points | At 20 o'clock | |
| Touch resolution | 32767*32767 | |
| Touch precision | ±1mm | |
| Single refers to the response speed | ＜8ms | |
| Touch number | The theoretical number is infinite | |
| drivers | System automatic identification, no drive | |
| support system | windowsXP /7/8/10/11,Android,MacOS,Linux | |
| working temperature | -10~+50 ℃ | |
| communication mode | USB 2.0/USB 3.0 | |
| Built-in system | scheme | Amlogic T982 |
| CPU | Quad-core ARM Cortex-A55 | |
| GPU | Mali-G52 MP2(2EE) | |
| basic frequency | 1.9GHz | |
| internal storage | 4G DDR | |
| memory | 32GB (EMMC) | |
| Wi-Fi | 2.4GHz/5GHz | |
| System version | Android 13.0 | |
| Front interface | Enter the port | USB×2 |
| HDMI×1 | ||
| TOUCH USB×1 | ||
| Prehole position | Auto photosensitive hole 1 | |
| Remote control receives the indicator light 1 | ||
| The machine interface | Enter the port | RJ45:×1 |
| TOUCH USB:×1 | ||
| USB3.0:×1 | ||
| USB2.0:×1 | ||
| RS232:×1 | ||
| HDMI IN:×2 | ||
| AV IN:×1 | ||
| Other ports | AV OUT:×1 | |
| Earphone:×1 | ||
| SPDIF OUT:×1 | ||
| Complete machine power consumption | The power of the machine | ≤880W |
| OPS power | ≤120W | |
| working voltage | 100~240V AC, 50/60Hz | |
| Standby power consumption | ≤0.5W | |
| Sound channel stereo | 2.0 | |
| Dual-channel power | 15W / 8 O. 2 speakers | |
| work environment | service temperature | 0~40℃ |
| operation humidity | 10%~90% RH | |
| Storage temperature | -20~60℃ | |
| Store humidity | 10%~90% RH | |
| above sea level | 5000 Meters | |
| Size weight | Standard bare machine size is long | 2503mm (length) * 109mm (width) * 1470mm (height) with OPS |
| Camera model naked machine ruler | 2503mm (length) * 109mm (width) * 1484mm (height) with OPS | |
| packing measurement | 2685mm (length) * 285mm (width) * 1710 (height) (world cover) | |
| VESA stent hole position (mm) | ||
| Wall hanging thickness (mm) | 36mm | |
| net weight | 130KG | |
| rough weight | 155KG | |
| Standard list | nameplate (neutral) | 1 (affixed on the back of the machine) |
| QR code (Neutral) | 1 (at bottom left of front box) | |
| Accessory box (neutral) | ×1 | |
| Power line 3 meters | ×1 | |
| Certificate (neutral) | ×1 | |
| Warranty Card (Neutral) | ×1 | |
| Remote control (no battery) | ×1 | |
| Touch the pen | ×2 | |
| Wall-hanger (neutral) | ×1 | |
| Optional list | HDMI line of 3 m | ×1 |
| TOUCH USB Line is 3 meters | ×1 | |
| Intelligent page turning pen | ×1 | |
| Wireless screen casting device | ×1 | |
| traversing carriage | ×1 |
If you would like to get the specification about above product, or you hope to discuss your requirements or need any additional information on our this product , then please do not hesitate to send us a inquiry and contact our sales team now.
|
|
